- Core Specifications:
Image Sensor: 1/2.7″ progressive scan CMOS, delivering full 1080p resolution at up to 30 fps
Lens: Fixed 4 mm (F2.0) lens with 90° horizontal/48° vertical/108° diagonal field of view
Illumination: Built in EXIR 2.0 infrared LEDs, 850 nm, up to 30 m night vision range; true day/night capability with IR cut filter
Day/Night Sensitivity: Color mode at 0.01 Lux (F2.0), switches to full B/W IR mode with 0 Lux in darkness - Video & Compression:
Resolutions: Main stream at 1080p/720p (25 fps PAL, 30 fps NTSC); sub streams at SD resolutions
Codecs: Efficient H.265+, H.265, H.264+, H.264, with MJPEG support for sub streams
Digital WDR, 3D DNR, and BLC provide improved image quality under challenging light - Network & Storage:
Protocols: TCP/IP, HTTP/S, FTP, DHCP, DNS, DDNS, RTP/RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, IPv4/6, SSL/TLS
Live View: Supports up to 6 concurrent streams; compatible with PRAMA VMS and web browsers
Note: Unlike the F(D) variant, this model does not include on board microSD storage. - Build & Connectivity:
Housing: Metal & plastic, IP67 rated for outdoor use; operates from –30 °C to +60 °C
Mount Adjustment: 360° pan, 180° tilt, 360° rotate .
Power: Protects up to 6.5 W; supports 12 VDC or PoE 802.3af (Class 3)
Ethernet: 1×RJ45 10/100 Mbps port - Budget friendly outdoor surveillance with clear IR night vision up to 30 m.
- Ideal for residential or small business deployment.
- PoE support simplifies installation, robust against weather and vandalism.
- Good for areas with moderate light variation due to Digital WDR and IR illumination.
PRAMA 2 MP IR Fixed Turret Network Camera/PT-NC120D3-I(DE)/White/Night Color
PRAMA 2 MP IR Fixed Turret Network Camera/PT-NC120D3-I(DE)/White/Night Color
PRAMA 2 MP IR Fixed Turret Network Camera/PT-NC120D3-I(DE)
KEY FEATURES :
- Resolution: 2 MP @1080p/30 fps
- Lens: 4 mm fixed (F2.0)
- IR Range: Up to 30 m
- Compression: H.265+/H.265/H.264+/H.264
- Storage: No memory card slot
- Audio: None
- Power: PoE or 12 VDC, ~6.5 W
- Protection: IP67, –30 °C to +60 °C
