Core Specifications:
Image Sensor: 1/2.8″ progressive‑scan CMOS
Resolution: 1920 × 1080, 25 fps (50 Hz) or 30 fps (60 Hz)
Lens: Fixed lens, available in 2.8 mm or 4 mm
Aperture: F1.0
Illumination & Color Technology:
Minimum Illumination: 0.001 Lux (color), 0 Lux with active light
Smart Hybrid Light: Combines IR and white LEDs up to 30 m, intelligently switching, ensuring full color video during events and lower power use otherwise
Video & Compression:
Streams: Main (1080p/720p), Sub (480p/360p) at up to 25/30 fps
Codec Support: H.265+/H.265/H.264+/H.264, MJPEG (sub-stream)
Audio & Intelligence:
Audio: Built‑in mono mic, supports G.711, AAC‑LC and others
Smart Detection: Human/vehicle classification with Smart Motion Detection 2.0
Storage & Connectivity:
On board storage: microSD slot (F variant only) up to 512 GB
Network: 10/100 Mbps Ethernet, PoE IEEE 802.3 af (Class 3) or 12 VDC power
Durability & Build:
Rating: IP67 weatherproof
Operating Temperature: –30 °C to +60 °C
Dimensions: Ø110 × 93 mm, Weight: ~380 g
The DS‑2CD1327G2H‑LIU(F) is perfect for reliable, full color outdoor surveillance with smart light activation and audio capabilities, great for residential or small scale commercial use.
