PRODUCT SPECIFICATION :

• Image Sensor & Resolution:
  Uses a 5 MP (2560 × 1944) CMOS sensor for high-definition analog output via HD‑TVI technology
• Lens Options & Field of View:
  Available with a fixed‑lens of 2.8 mm (FoV approx. 110.7° diag, 85.5° horizontal) or 3.6 mm (approx. 105.9° diag, 80.1° horiz)
• Night Vision:
  Equipped with EXIR 2.0 infrared illumination for up to 20 m (65 ft) visibility in low-light
• True Detect PIR & Alarm Features:
  Built-in PIR sensor detects human motion reliably; triggers a white light strobe alarm and activates alarm output for intruder deterrence
• Weather Resistance:
  Rated IP67, fully protected against dust and water—suitable for rugged outdoor use
• Analog Transmission:
  Uses TurboHD/HD‑TVI analog signaling, enabling full HD video over existing coax cable infrastructure. Supports Up-the-Coax telemetry control via compatible Hikvision DVRs
• Turret Form Factor:
  Compact and dome‑like design enabling flexible pan (0–360°), tilt (0–75°), and rotation (0–360°) adjustment
• Materials & Dimensions:
  Outer enclosure is plastic; internal body is metal. Dimensions ~ 110 mm × 90 mm; weight ~ 310–327 g
• Frame Rates (TVI Signal):
  Supports 5 MP @ 20 fps, 4 MP @ 25/30 fps, and down to HD 1080p @ 25/30 fps
• Sensitivity & Modes:
  Minimum illumination of 0.01 Lux (F2.0, AGC on), or 0 Lux with IR active. Includes ICR day/night switching, color in day and black‑white at night
• Image Controls:
  Image parameters—brightness, sharpness, DNR, Smart IR, mirror settings—with selectable modes like Standard/High Saturation
• Alarm LEDs & Duration:
  The integrated white light strobe can flash (~4 Hz for ~12 sec) or stay continuously on for customizable 5–60 sec intervals via DVR/OSD controls
• Operating Conditions:
  Rated for extreme climates: –40 °C to 60 °C, up to 90% non-condensing humidity
• Power Supply & Consumption:
  Requires 12 V DC, consuming around 3.5–4.5 W
