About this item

Smart Surveillance & Analytics :

• Intelligent Motion Detection: Supports human/vehicle classification across all analog channels—significantly reduces false alarms.
• Perimeter Protection: Includes line crossing and intrusion alerts on 4 selectable channels.

Input & Recording Support :

• Analog Video Inputs: 16 BNC ports supporting HDTVI, AHD, CVI, and CVBS formats with up to 4 MP Lite resolution.
• IP Camera Inputs: 2 native IP channels (expandable up to 18 channels in standard mode, or 24 in enhanced mode)
• supporting up to 6 MP IP cameras.
• Recording Resolutions: Full channel recording at 4 MP Lite, 1080p, WD1, CIF etc.; dual stream setup enables parallel high and low resolution feeds.

Video Encoding & Storage Efficiency :

• Compression: Supports H.265 Pro+, H.265 Pro, H.265, H.264+, and H.264 to maximize storage efficiency.
• Bandwidth Handling: Up to 96 Mbps total incoming bandwidth (48 Mbps in enhanced IP mode).
• Storage: One SATA port with support for up to 10 TB HDD (varies by setup).

Output & Remote Access :

• Video Outputs: 1×VGA (1080p max) and 1×HDMI (up to 4K); outputs can run simultaneously.
• Audio: 1×RCA mic input, up to 16 analog channel audio via coax, plus 1×RCA line out; supports two way audio.
• Network & Remote: 1×RJ45 10/100/1000 Mbps port; supports up to 128 concurrent remote connections; brands IP on up to 96 Mbps bandwidth.

Additional Features :

• Smart Search: Quickly zero in on events flagged by motion or perimeter triggers.
• Dual Stream Capacity: Authorized high and lower resolution streams together for efficient remote viewing.
